Crane Wheel
Precision-Engineered for Smooth Travel & High Load Capacity
30+ Years Manufacturing Experience
Exported to 130+ Countries
Custom Design Within 24 Hours
Crane Parts
Crane Wheel
Durable Crane Travelling Component for Stable and Efficient Operation
Reliable crane wheels are essential for the safe and stable operation of overhead cranes, gantry cranes, transfer carts, and other heavy lifting equipment. At Weihua, we manufacture high-quality crane wheels designed for long service life, smooth travelling performance, and demanding industrial environments.
Trusted by Global Industrial Clients
5000+ Crane Projects Delivered
ISO / CE Certified Manufacturer
Serving Steel, Logistics, and Construction Industries
24/7 Technical Support
Share To:
- Overview
- Features
- Applications
- Specifications
- Design
- Why-Us
- Faq
Products Overview
The crane wheel is one of the key components used in overhead cranes, gantry cranes, transfer carts, and other material handling equipment. It supports the movement of the crane along rails and directly affects travelling stability, operating efficiency, and service life.
Weihua Crane’s crane wheels are manufactured with high-strength materials and precision machining technology to ensure reliable performance under continuous industrial operation. Depending on working conditions, different wheel structures and heat treatment processes can be provided to improve wear resistance and load capacity.
Key Features
Our crane wheels are widely used in steel plants, ports, warehouses, and heavy manufacturing industries.
01
High Load-Bearing Capacity
Designed for heavy-duty crane travelling applications.
02
Wear-Resistant Material
Heat-treated surface improves durability and service life.
03
Precision Machining
Ensures smooth running and stable operation on rails.
04
Flexible Configuration
Different wheel structures available for various crane systems.
05
Reliable Performance
Suitable for continuous industrial use in demanding environments.
Typical Applications
Crane wheels are widely used in:
-
Port Crane SolutionsThe volume of containers, bulk cargo, and general cargo handled by modern ports continues to increase every year. Efficient port crane systems help ports improve cargo turnover, shorten vessel turnaround times, and maintain smooth logistics operations.
-
Steel Industry Lifting SolutionsThe steel industry demands robust and reliable lifting solutions.
-
Crane Parts SolutionsOnce a crane is put into production use, its performance is evaluated not only by the overall machine quality, but also by the compatibility of each component with the complete system. Whether it is the hook, drum, or grab, all these crane parts directly affect lifting efficiency, operator safety, and subsequent maintenance costs.
-
Electric Flat Transfer Cart SolutionsElectric flat transfer carts provide an efficient solution for internal material transportation. Manufacturers use them to move raw materials, semi-finished products, finished goods, and heavy equipment across production facilities
They are essential components for crane travelling systems.
Technical Specifications
The following specifications are for standard reference. Weihua Crane can provide customized solutions based on actual project requirements.
| Model | Wheel Diameter (mm) | Tread Width (mm) | Material | Heat Treatment | Load Capacity (Ton) | Applicable Equipment |
| CW-200 | 200 | 60 | 45# Steel | Quenched & Tempered | 2 – 5 | Small Overhead Crane |
| CW-300 | 300 | 70 | 42CrMo | Surface Hardening | 5 – 10 | Overhead Crane |
| CW-400 | 400 | 80 | 42CrMo | Surface Hardening | 10 – 20 | Gantry Crane |
| CW-500 | 500 | 90 | ZG340-640 | Heat Treated | 20 – 32 | Heavy Gantry Crane |
| CW-700 | 700 | 100 | Alloy Steel | Heat Treated | 32 – 50 | Port Crane |
| CW-900 | 900 | 120 | Alloy Steel | Heat Treated | 50 – 100 | Heavy-Duty Port Crane |
Note: All parameters can be customized based on your project requirements.
Not sure which model fits your project? Contact our engineers for selection support.
Customization Options
Weihua Crane offers customized crane wheel solutions based on working conditions and equipment requirements:
Different wheel diameters and tread widths
Forged or cast wheel structures
Heat treatment and surface hardening options
Single flange or double flange design
Adaptation to different rail types and crane systems
Our engineering team will recommend the most suitable wheel configuration for your project.
Why Choose Weihua Crane
Weihua has extensive experience in crane components manufacturing and industrial lifting solutions. Our crane wheels are designed for durability, stability, and long-term operation.
High-quality raw materials and machining
Reliable performance under heavy-duty conditions
Flexible customization capability
Support for various crane and transfer systems
Frequently Asked Questions
Need Help Choosing the Right Crane Wheel?
Selecting the correct crane wheel depends on load capacity, rail type, and operating conditions.
Here are some common questions to help you better understand the product.
If you need further assistance, our team is ready to support you.
Common materials include forged steel, alloy steel, and heat-treated cast steel depending on working requirements.
Forged wheels generally provide better strength and wear resistance, while cast wheels are more economical for certain applications.
Yes, wheel diameter, width, material, and heat treatment can all be customized based on project requirements.
They are widely used in overhead cranes, gantry cranes, port cranes, and rail transfer carts.
Please provide wheel size, load capacity, rail type, and equipment application for accurate recommendation.
Get a Quote
To provide a suitable solution, please share:
- Wheel diameter requirements
- Load capacity
- Crane type or equipment model
- Working environment
We will respond within 24 hours with a practical recommendation.
