Single Arm Crane
Flexible and Efficient Lifting Solution by Weihua Crane
30+ Years Manufacturing Experience
Exported to 130+ Countries
Custom Design Within 24 Hours
Jib Crane
Single Arm Crane
The Single Arm Crane, also known as a jib crane, is designed for localized lifting tasks where flexibility and efficiency are essential. It is widely used in workshops, warehouses, assembly lines, and maintenance areas to handle materials quickly and safely.
Trusted by Global Industrial Clients
5000+ Crane Projects Delivered
ISO / CE Certified Manufacturer
Serving Steel, Logistics, Construction Industries
24/7 Technical Support
Share To:
- Overview
- Features
- Applications
- Specifications
- Design
- Why-Us
- Faq
Products Overview
Compared with large overhead cranes, a single arm crane offers a cost-effective solution for repetitive lifting within a fixed working area. Its simple structure, easy operation, and reliable performance make it an ideal choice for improving productivity without complex installation.
Weihua Crane provides robust and practical single arm crane systems tailored to real industrial needs.
Key Features
The single arm crane is designed to simplify lifting operations in limited working areas:
01
360° rotation or customized rotation angle
02
Compact structure, easy to install and relocate
03
Independent lifting system for localized operations
04
Smooth slewing movement with manual or motorized rotation
05
Suitable for indoor and outdoor use
06
Low maintenance and long service life
07
Can be integrated with electric hoists for improved efficiency
Typical Applications
Single arm cranes are widely used for light to medium-duty lifting tasks:
-
Port Crane SolutionsThe volume of containers, bulk cargo, and general cargo handled by modern ports continues to increase every year. Efficient port crane systems help ports improve cargo turnover, shorten vessel turnaround times, and maintain smooth logistics operations.
-
Electric Flat Transfer Cart SolutionsElectric flat transfer carts provide an efficient solution for internal material transportation. Manufacturers use them to move raw materials, semi-finished products, finished goods, and heavy equipment across production facilities
-
Gantry Crane SolutionsThe gantry crane is suitable for outdoor material handling. The gantry structure enables it to serve storage areas, production zones, and construction sites without relying on building structures. In addition, it offers stable lifting and accurate load positioning, which helps enhance material handling efficiency.
-
Port & Shipyard Lifting SolutionsPort terminals and shipyards operate in demanding environments where lifting equipment must handle large loads, long shifts, and harsh conditions.
They are especially useful for repetitive lifting in a fixed area, reducing dependence on larger crane systems.
Technical Specifications
| Item | Specification | Unit | Description | Options | Remark |
| Lifting Capacity | 0.25 – 10 | ton | Standard range | Custom available | Based on usage |
| Arm Length | 2 – 10 | m | Working radius | Adjustable | Site-based design |
| Lifting Height | 2 – 12 | m | Standard height | Customizable | Workshop dependent |
| Rotation Angle | 180° / 270° / 360° | — | Slewing range | Optional | Full rotation available |
| Lifting Speed | 0.8 – 8 | m/min | Hoist speed | VFD optional | Smooth lifting |
| Rotation Type | Manual / Electric | — | Standard/manual | Motorized optional | Flexible choice |
| Power Supply | 220 – 480 | V | 3-phase | 50/60Hz | International standard |
| Installation Type | Floor / Wall Mounted | — | Standard | Custom design | Space dependent |
Note: All parameters can be customized based on your project requirements.
Not sure which model fits your project? Contact our engineers for selection support.
Custom Solutions for Different Applications
Every workshop layout is different, and lifting requirements vary depending on the workflow. Weihua Crane offers custom-built single arm crane solutions to ensure the equipment fits your exact application.
We can customize:
Arm length and rotation range based on workspace
Column height or wall-mounted structure design
Lifting capacity according to material handling needs
Electric or manual rotation depending on operation frequency
Special voltage and electrical configurations
Integration with electric hoists or other lifting systems
Solutions for outdoor, corrosive, or high-temperature environments
Our engineers will evaluate your layout and recommend a practical configuration that improves efficiency without unnecessary cost.
Why Choose Weihua Crane?
Weihua Crane focuses on delivering practical and reliable lifting solutions:
Strong customization capability for non-standard projects
Stable and durable structural design
Easy installation and minimal downtime
Strict quality control and testing procedures
Fast technical support and global servic
We aim to provide equipment that fits your workflow — not the other way around.
Frequently Asked Questions
A single arm crane is used for localized lifting tasks within a fixed area, such as assembly lines, workshops, and maintenance stations.
Yes, both the arm length and rotation angle can be customized to match your workspace and operational requirements.
Floor-mounted cranes are installed on the ground with a column, while wall-mounted cranes are fixed to building structures, saving floor space.
For light-duty or occasional use, manual rotation is sufficient. For frequent operations, electric rotation improves efficiency and reduces labor.
Yes, Weihua Crane provides technical guidance, installation support, and long-term after-sales service worldwide.
Get a Quote
To receive an accurate quotation, please provide:
- Lifting capacity
- Span and lifting height
- Working environment
- Power supply
We will respond within 24 hours with a suitable solution.
