Single Girder Overhead Crane
Efficient and Cost-Effective Lifting Solution for Workshops
30+ Years Manufacturing Experience
Exported to 130+ Countries
Custom Design Within 24 Hours
Overhead Crane
Single-Girder Overhead Crane
A single girder overhead crane is one of the most popular lifting solutions for industrial workshops and production facilities. The crane features a single bridge girder, while the hoist travels along the lower flange to lift and move loads efficiently across the working area.
Trusted by Global Industrial Clients
5000+ Crane Projects Delivered
ISO / CE Certified Manufacturer
Serving Steel, Logistics, Construction Industries
24/7 Technical Support
Share To:
- Overview
- Features
- Applications
- Specifications
- Design
- Why-Us
- Faq
Products Overview
Many manufacturers, warehouses, and assembly plants choose single girder overhead cranes because they combine reliable performance with cost-effective operation. Compared with a double girder crane, this design requires less steel and fewer components. As a result, businesses can reduce equipment investment while still meeting most light- and medium-duty lifting needs.
In addition, the compact structure helps operators make better use of available space. Therefore, single girder overhead cranes work particularly well in facilities with limited headroom or restricted installation conditions.
Key Features
01
Compact Structure
Optimized design reduces overall height and improves space utilization.
02
Cost-Effective Solution
Lower material and installation cost compared to double girder cranes.
03
Stable and Reliable Operation
Mature design ensures consistent performance in daily use.
04
Easy Installation and Maintenance
Simple structure makes installation faster and maintenance more convenient.
05
Flexible Configuration
Can be equipped with electric wire rope hoist or chain hoist.
Typical Applications
Single girder overhead cranes are widely used in:
-
Steel Industry Lifting SolutionsThe steel industry demands robust and reliable lifting solutions.
-
Port & Shipyard Lifting SolutionsPort terminals and shipyards operate in demanding environments where lifting equipment must handle large loads, long shifts, and harsh conditions.
-
Manufacturing Industry Lifting SolutionsManufacturing environments rely on consistent and efficient material handling to keep production lines running smoothly.
-
KBK Crane SystemsLifting SolutionsKBK crane systems provide a flexible and efficient lifting solution for modern manufacturing facilities. With their modular suspended design, these cranes help move materials safely and accurately while maximizing available workspace.
They are suitable for most general-purpose lifting tasks.
Technical Specifications
The following specifications are for standard reference. Weihua Crane can customize according to your project requirements.
| Model | Capacity (Ton) | Span (m) | Lifting Height (m) | Hoisting Speed (m/min) | Trolley Speed (m/min) | Crane Speed (m/min) | Working Duty |
| LD-10 | 1 | 7.5 – 22 | 6 – 12 | 8 / 0.8 | 20 – 30 | 20 – 40 | A3 |
| LD-20 | 2 | 7.5 – 22 | 6 – 12 | 8 / 0.8 | 20 – 30 | 20 – 40 | A3 |
| LD-50 | 5 | 10 – 25 | 6 – 18 | 8 / 0.8 | 20 – 30 | 20 – 40 | A4 |
| LD-100 | 10 | 10 – 28 | 6 – 18 | 7 / 0.7 | 20 – 35 | 25 – 45 | A4 |
| LD-160 | 16 | 10 – 30 | 6 – 20 | 3.5 / 0.7 | 25 – 35 | 25 – 50 | A5 |
| LD-200 | 20 | 10 – 31.5 | 6 – 20 | 3.5 / 0.7 | 25 – 40 | 30 – 50 | A5 |
Note: All parameters can be customized based on your project requirements.
Not sure which model fits your project? Contact our engineers for selection support.
Customized Design Options
Weihua Crane can provide tailored solutions based on different working conditions:
Customized span and lifting height
Low headroom design
Different hoist configurations
Power supply adaptation (220V / 380V / 415V)
Control methods (pendant / remote / cabin)
Our engineers will recommend a suitable configuration based on your actual usage.
Why Choose Weihua Crane ?
Weihua has extensive experience in overhead crane manufacturing and export projects. Our single girder cranes are designed for reliable daily operation and long service life.
Our strengths include:
Proven design for industrial use
Stable quality and performance
Flexible customization capability
Fast response for international customers
Frequently Asked
Questions
Have questions about our single girder overhead crane? Here are some of the most common concerns from our customers.
If you still need more details, feel free to contact our team — we’re here to help you find the right solution.
A single girder overhead crane offers a practical and cost-effective lifting solution for many industries. Because of its simpler design, installation and maintenance often require less time and lower costs. At the same time, the crane delivers reliable performance for daily material handling operations.
Standard single girder overhead cranes generally handle loads up to 20 tons. However, higher capacities may be available for specific projects. Our engineering team can recommend a suitable solution according to your operating requirements.
Yes. Many customers select low-headroom configurations when they need to maximize lifting height within limited building space. As a result, operators can achieve greater lifting efficiency without modifying the existing workshop structure.
Customers can choose either an electric wire rope hoist or an electric chain hoist. For example, chain hoists often suit lighter lifting applications, whereas wire rope hoists typically perform better in higher-capacity and longer-lift operations.
To help us recommend the right model, please provide the lifting capacity, span, lifting height, working environment, and power supply information. Once we receive these details, we can prepare a suitable technical proposal and quotation more efficiently.
Get a Quote
To receive an accurate quotation, please provide:
- Lifting capacity
- Span and lifting height
- Working environment
- Power supply
We will respond within 24 hours with a suitable solution.
