Single Girder Gantry Crane
for Efficient Outdoor Lifting Solutions
30+ Years Manufacturing Experience
Exported to 130+ Countries
Custom Design Within 24 Hours
Gantry Crane
Single-Girder Gantry Crane
A Single Girder Gantry Crane is a cost-effective lifting solution designed for outdoor and semi-outdoor environments such as yards, warehouses, and fabrication areas.
Trusted by Global Industrial Clients
5000+ Crane Projects Delivered
ISO / CE Certified Manufacturer
Serving Steel, Logistics, and Construction Industries
24/7 Technical Support
Share To:
- Overview
- Specifications
- Features
- Applications
- Design
- Why-Us
- Cases
- Faq
Products Overview
What is a Single Girder Gantry Crane?
A Single Girder Gantry Crane is a cost-effective lifting solution designed for outdoor and semi-outdoor environments such as yards, warehouses, and fabrication areas. Compared to double girder systems, it offers a simpler structure, easier installation, and lower investment—making it a practical choice for small to medium lifting tasks.
This type of crane typically runs on ground-mounted rails and is widely used where overhead runway beams are not available.
Technical Specifications
Quickly find the right model for your lifting needs:
Below is a standard model reference (customization available):
| Model | Lifting Capacity | Span (m) | Lifting Height (m) | Working Class | Power Supply |
| MH 3T | 3 Ton | 12–20 | 6–9 | A3 | 380V / 50Hz |
| MH 5T | 5 Ton | 12–25 | 6–12 | A3-A4 | 380V / 50Hz |
| MH 10T | 10 Ton | 16–30 | 9–12 | A3-A5 | 380V / 50Hz |
| MH 16T | 16 Ton | 18–35 | 9–12 | A4-A5 | 380V / 50Hz |
| MH 20T | 20 Ton | 20–40 | 9–15 | A5 | 380V / 50Hz |
Note: All parameters can be customized based on your project requirements.
Not sure which model fits your project? Contact our engineers for selection support.
Key Features & Advantages
01
Cost-Effective Structure
Single girder design reduces steel usage and overall cost.
02
Easy Installation
No need for complex building support structures.
03
Flexible Operation
Can be equipped with electric hoist or wire rope hoist.
04
Outdoor Ready
Designed to withstand wind, rain, and dust conditions.
05
Low Maintenance
Simple mechanical structure ensures long-term reliability.
Typical Applications
Single girder gantry cranes are widely used in:
-
Jib Crane Lifting SolutionsA jib crane is a type of lifting equipment. Its horizontal boom is connected to a vertical support and can rotate at multiple angles, enabling radial lifting movement within a fixed working area.
-
Warehouse & Logistics Lifting SolutionsIn warehouse and logistics operations, speed and accuracy matter just as much as safety.
-
Electric Hoist Lifting SolutionsAn electric hoist is a mobile lifting device widely used in industrial production and material handling. It effectively reduces manual labor while enhancing workplace safety and efficiency, making it the top choice for many companies.
-
Crane Parts SolutionsOnce a crane is put into production use, its performance is evaluated not only by the overall machine quality, but also by the compatibility of each component with the complete system. Whether it is the hook, drum, or grab, all these crane parts directly affect lifting efficiency, operator safety, and subsequent maintenance costs.
Customized Design Options
We provide tailored solutions based on your working conditions:
Cantilever Design (single or double side)
Electric Hoist Options (CD/MD or European type
Control Methods (pendant, remote control, cabin)
Weather Protection Systems
Anti-sway & frequency conversion systems
Our engineering team ensures every crane fits your exact lifting needs.
Why Choose Weihua Group ?
As one of the leading crane manufacturers in China, Weihua Group has built a strong global reputation in material handling equipment.
Our strengths include:
Over 30 years of manufacturing experience
Exported to 130+ countries
Advanced production facilities and strict quality control
Certified with ISO, CE, SGS standards
Strong engineering and customization capability
We don’t just supply cranes — we deliver complete lifting solutions.
Project Cases
Steel Fabrication Plant – Southeast Asia
- Industry: Steel Manufacturing & Scrap Handling
- Equipment Supplied: Intelligent Heavy-Duty Gantry Cranes
- Main Specifications: 30m Lifting Height / 85m Span / 50m Gauge
- Application: Scrap Steel Yard Handling Operations
Logistics Yard – Middle East
- Project Type: Container Handling Equipment for Port Operations
- Destination: Africa
- Equipment Supplied: Customized Heavy-Duty Container Gantry Cranes
- Current Progress: Factory Acceptance Test Completed / Shipment Preparation Underway
Frequently Asked
Questions
Here are quick answers to the most common questions from our clients. Want more answers? Ask us or explore more!
Single girder cranes are lighter, more affordable, and suitable for medium-duty work, while double girder cranes handle heavier loads and higher duty cycles.
Yes, it is specifically designed for outdoor environments and can include weather protection features.
Typically 20–40 days depending on customization requirements.
Yes, we can offer installation guidance, remote support, or dispatch engineers if needed.
Absolutely. We specialize in tailored lifting solutions.
Get Your Custom Crane Solution
Looking for a reliable Single Girder Gantry Crane supplier?
Contact us today to get:
- Free consultation
- Custom design
- Competitive quotation
