Pillar Jib Crane
Reliable and Flexible Lifting Solution by Weihua Crane
30+ Years Manufacturing Experience
Exported to 130+ Countries
Custom Design Within 24 Hours
Jib Crane
Pillar Jib Crane
The Pillar Jib Crane is a versatile lifting system designed for independent operation within a fixed working area. Installed on a floor-mounted column, it provides efficient material handling without relying on existing building structures.
Trusted by Global Industrial Clients
5000+ Crane Projects Delivered
ISO / CE Certified Manufacturer
Serving Steel, Logistics, Construction Industries
24/7 Technical Support
Share To:
- Overview
- Features
- Applications
- Specifications
- Design
- Why-Us
- Faq
Products Overview
This type of crane is widely used in workshops, warehouses, and production lines where localized lifting is required. With its simple structure, smooth rotation, and easy operation, the pillar jib crane helps improve workflow efficiency while reducing manual handling.
Weihua Crane offers durable and practical pillar jib crane systems tailored to real industrial applications.
Key Features
The pillar jib crane is designed to deliver reliable performance in everyday lifting tasks:
01
Free-standing column design, no need for building support
02
Wide rotation range for flexible material handling
03
Smooth slewing movement with low resistance
04
Compact footprint, suitable for various layouts
05
Easy installation and relocation
06
Compatible with electric hoists for efficient lifting
07
Low maintenance and long service life
Typical Applications
Pillar jib cranes are widely used for localized lifting across various industries:
-
Energy & Power Plant Lifting SolutionsPower plants and energy facilities require lifting equipment that can handle critical components with care and stability.
-
Warehouse & Logistics Lifting SolutionsIn warehouse and logistics operations, speed and accuracy matter just as much as safety.
-
Gantry Crane SolutionsThe gantry crane is suitable for outdoor material handling. The gantry structure enables it to serve storage areas, production zones, and construction sites without relying on building structures. In addition, it offers stable lifting and accurate load positioning, which helps enhance material handling efficiency.
-
Automotive Industry Lifting SolutionsAutomotive production lines depend on smooth and well-coordinated material handling at every stage.
They are ideal for reducing manual labor and improving efficiency in fixed working areas.
Technical Specifications
| Item | Specification | Unit | Description | Options | Remark |
| Lifting Capacity | 0.25 – 10 | ton | Standard range | Custom available | Based on application |
| Arm Length | 2 – 10 | m | Working radius | Adjustable | Site-specific design |
| Lifting Height | 2 – 12 | m | Standard height | Customizable | Workshop dependent |
| Rotation Angle | 180° / 270° / 360° | — | Slewing range | Optional | Full rotation available |
| Lifting Speed | 0.8 – 8 | m/min | Hoist speed | VFD optional | Smooth lifting |
| Rotation Type | Manual / Electric | — | Standard/manual | Motorized optional | Flexible operation |
| Power Supply | 220 – 480 | V | 3-phase | 50/60Hz | International standard |
| Installation Method | Anchor Bolt / Foundation | — | Floor mounted | Custom design | Stable installation |
Note: All parameters can be customized based on your project requirements.
Not sure which model fits your project? Contact our engineers for selection support.
Custom Solutions for Your Application
No two workshops are exactly the same. The effectiveness of a pillar jib crane depends on how well it matches your workspace and operational needs.
Weihua Crane provides custom-designed pillar jib crane solutions to ensure optimal performance:
Custom column height and arm length based on layout
Adjustable rotation range for specific working zones
Selection of manual or motorized rotation systems
Integration with different types of electric hoists
Custom voltage and control systems for global markets
Reinforced structures for heavy-duty or continuous operation
Design adaptations for outdoor or harsh environments
Our engineers can evaluate your workspace and recommend a configuration that improves efficiency while keeping installation simple and cost-effective.
Why Choose Weihua Crane?
Weihua Crane focuses on delivering practical lifting solutions that meet real operational needs:
Strong customization capability for non-standard projects
Stable and durable structural design
Easy installation with minimal disruption
Strict quality control and testing procedures
Responsive technical support and global service
We provide solutions that integrate smoothly into your workflow and help improve productivity.
Frequently Asked Questions
A pillar jib crane is used for localized lifting tasks within a fixed area, such as workstations, warehouses, and production lines.
Yes, the pillar jib crane is floor-mounted with its own column, so it does not rely on existing building structures.
Yes, both the arm length and column height can be customized based on your layout and lifting needs.
Manual rotation is suitable for light-duty use, while electric rotation is recommended for frequent operations to improve efficiency.
Yes, Weihua Crane offers technical support, installation guidance, and after-sales service for global customers.
Get a Quote
To receive an accurate quotation, please provide:
- Lifting capacity
- Span and lifting height
- Working environment
- Power supply
We will respond within 24 hours with a suitable solution.
